Introduction

Overview

The Elongate is a personal project of MrKeebs, and the PCB is a joint project between him and me. It features a very straightforward 50% staggered layout (basically a 40% with numpad).

Preview

The ./renders/pcb folder shows the renders of the current PCB version, generated by the tracespace engine. Click the images to zoom in.

../_images/top.png
../_images/bottom.png

Features

The ElongatePCB is a freely available, open-source 50% keyboard Printed Circuit Board (PCB) supporting a single layout, consisting of a 40% staggered layout with split spacebar. Here’s a list of the board’s features:

  • AVR ATMEGA32U4 processor;
  • QMK firmware compatible;
  • USBC type connector;
  • No LEDs whatsoever;
  • Single layout support;
  • Hardware reset through a push button and reset network;
  • Overcurrent and overvoltage input protection through a fuse and schottky diode;
  • Electrical Static Discharge (ESD) protection through a discharge net.
